Electrical
Rated Voltage
250V
Rated Current
4A
Insulation Resistance
≥100MΩ
Contact Resistance
≤3mΩ
Impulse Voltage
2500 V
Pollution Degree
3
M12 Panel Mount Socket / M12 Circular Connectors
M12 A-Coding Male Straight Front Lock Panel Mount Socket, 3-Pin, M12×1.0
PN 120401030100
250V · 4AIP67/IP68
Configure Your Product
Pin
Coding
Gender
Orientation
Termination
Mounting Type
Part Number
/ Specifications
Technical Details
Mechanical & Connection
Termination
PCB
Shielding
false
Mounting Thread
M12×1.0
Locking System
M12x1.0 Screw Lock
Mounting Type
Front Lock
Tightening Torque
Recommended: 0.6 Nm; Max: 1.0 Nm
Materials & Environmental
Housing Material
Metal
IP Rating
IP67/IP68
Reference Standard
IEC 61076-2-101
Operating Temperature
-25°C to +80°C
Contact Material
Brass
Contact Plating
Gold (Au)
Screw Nut Material
Brass, nickel-plated
O-Ring
FKM / Silicone
