Electrical
Rated Voltage
60V
Rated Current
1A
Insulation Resistance
≥100MΩ
Contact Resistance
≤3mΩ
Impulse Voltage
500 V
Pollution Degree
3
M5 Panel Mount Socket / M5 Circular Connectors
M5 A-Coding Male Straight Front Lock Panel Mount Socket, 3-Pin
PN 050401030100
60V · 1AIP67/IP68
Configure Your Product
Pin
Gender
Termination
Mounting Type
Mounting Thread
Structure
/ Specifications
Technical Details
Mechanical & Connection
Termination
PCB
Shielding
false
Mounting Thread
M5x0.5
Locking System
M5x0.5 Screw Lock
Mounting Type
Front Lock
Structure
Panel Front Side Fastening
Tightening Torque
Recommended: 0.15 Nm; Max: 0.2 Nm
Materials & Environmental
Housing Material
Metal
IP Rating
IP67/IP68
Reference Standard
IEC 61076-2-105
Operating Temperature
-25°C to +80°C
Contact Material
Brass
Contact Plating
Gold (Au)
Screw Nut Material
Brass, nickel-plated
O-Ring
FKM / Silicone
